JBL 308PMKII

JBL 308P MkII

Powered 8" (20.32 cm) Two-Way Studio Monitor

Variations
Rp 9,800,000.009800000.0 each
For Bulk Enquiry: Click Here

Features

Patented Image Control Waveguide

Patented Image Control Waveguide

For detailed imaging and a broad, room-friendly sweet spot

Next-generation JBL transducers

Next-generation JBL transducers

For optimized transient response and improved linearity

New Boundary EQ settings

New Boundary EQ settings

Compensate for low frequency variants introduced by the environment

3-position HF Trim switch

3-position HF Trim switch

Adjusts high-frequency output to room acoustics or personal preferences

Patented Slip Stream™ low-frequency port

Patented Slip Stream™ low-frequency port

For superior bass performance at all playback levels

Dual integrated, custom Class-D amplifiers

Dual integrated, custom Class-D amplifiers

Provide 112 watts of power for high output and dynamic range

Flexible connectivity

Flexible connectivity

With balanced XLR and 1/4" TRS inputs, +4dBu / -10dBV input-sensitivity switch and adjustable volume control

Engineered to JBL Linear Spatial Reference design criteria

Engineered to JBL Linear Spatial Reference design criteria

For outstanding accuracy in any working space

Strenuous JBL 100-hour full-power test

Strenuous JBL 100-hour full-power test

Ensures years of reliability

Sleek, modern design

Sleek, modern design

Provides a visual upgrade to any studio

Frequently Bought Together

Specs & Downloads

Item# 308PMKII

Product Description

Powered 8" Two-Way Studio Monitor

The next-generation JBL 308P MkII powered studio monitor makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers, JBL 308P MkII offers stunning detail, precise imaging, a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace. Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors and sporting a sleek, modern design, JBL 308P MkII delivers outstanding performance and an enjoyable mix experience at an accessible price.

General Specifications

LF Driver Size 203 mm (8")
HF Driver Size 25 mm (1")
HF Driver Type Soft dome
Crossover 1800Hz 4th order acoustic Linkwitz-Riley
Power Configuration Bi-amplified
HF Driver Power Amp 56 W Class D
LF Driver Power Amp 56 W Class D
Frequency Response 45Hz – 20kHz (±3dB)
Frequency Range 37Hz – 24kHz (-10dB)
Low Frequency Extension 37Hz (-10dB)
Maximum Continuous SPL 102dB
Maximum Peak SPL 112dB
Maximum Peak Input Level +6dBV / +20.3dBu (-10dBV / +4dBu)
System Distortion Criteria <10% THD at maximum output with full compressor / limiter engagement
Electrical Distortion Criteria 0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output
Signal to Noise Ratio 75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output
Coverage Pattern 120° x 90° (horizontal x vertical)
HF Trim Control -2dB, 0dB, +2dB
Boundary EQ LF Shelf @ 50Hz
AC Input Voltage 100 – 240VAC (±10%), 50 / 60Hz

Dimensions

Height 419 mm (16.5")
Width 254 mm (10")
Depth 308 mm (12.1")
Net Weight 8.1 kg (17.87 lbs)

Design

Enclosure Type Ported
Enclosure Construction 15mm MDF
Enclosure Finish Matte black PVC
Baffle Construction Injection-molded structural ABS

Audio Input

Analog Input Types 1 x XLR female, 1 x TRS female, balanced
Input Sensitivity 92dB / 1m (-10dBV Input)

What's in the box?

  • 1 x 308P MkII studio monitor
  • 1 x Power cord
  • 1 x Quick setup guide
  • 4 x Peel-off rubber pads
JBL CLub One Box visual

Documents & Downloads

What the Pro’s are Saying

34th NAMM TEC Awards:

34th NAMM TEC Awards:

“Winner- Best Studio Monitors”

Mix Magazine:

Mix Magazine:

“The 308P MkII provides sound quality and performance that’s well above its price class. You’d be hard pressed to find an 8-inch monitor that offers a better value.”

MusicAlley.com:

MusicAlley.com:

“Gives detailed imaging and ensures recordings benefit from greater ambiance and depth.”

Music Connection:

Music Connection:

“I am left with an overall great impression of the JBL 308P, you can have a proper 2.1 or 5.1 system for a few dollars as possible it seems. Go for it!”
